VE-S6 Stereoscopic Binocular Microscope with Zoom System
VE-S6 Stereoscopic Binocular Microscope with Zoom System
VE-S6 Stereoscopic Binocular Microscope with Zoom System
VE-S6 Stereoscopic Binocular Microscope with Zoom System
VE-S6 Stereoscopic Binocular Microscope with Zoom System
VE-S6 Stereoscopic Binocular Microscope with Zoom System
VE-S6 Stereoscopic Binocular Microscope with Zoom System
VE-S6 Stereoscopic Binocular Microscope with Zoom System
VE-S6 Stereoscopic Binocular Microscope with Zoom System
VE-S6 Stereoscopic Binocular Microscope with Zoom System

VE-S6 Stereoscopic Binocular Microscope with Zoom System

The VE-S6 is the ideal for professional use in higher education, research and industrial procedures. A versatile device, useful in production procedures or quality inspection of industrial products, thanks to its zoom system.

Its Greenough design allows three-dimensional observation of insects and possesses a wide field of observation provided by its eyepieces. The VE- S6 is the perfect device for the dissection and classification of organisms in entomology and taxonomy, as well as livestock for the observation and selection of viable embryos.

Eyepiece: WF 10x/22 mm
Objectives:Variable magnifications zoom System 0.67X, 0.7X, 0.8X, 1X, 1.5X, 2X, 3X, 4X and 4.5X (6.7 to 45 total increases)
Stage: Interchangeable 95 mm/3.7" diameter stage, opaque glass and double-sided white/black
Focus: Coarse anti-slip control knob
Ilumination: Transmitted and incident  LED
Power supply: 110/240V, 50/60 Hz AC adapter.

Dimensions: 245 x 435 x 312 mm / 9.6" x 17.1" x 12.2"



  • Binocular head, inclined at 45 °.
  • Interpupillary distance of 55 ~ 75mm
  • Two interchangeable plates: opaque glass, for transmitted light and double-sided white / black, for incident light.
  • Diopter adjustment in both eyepieces.
  • Anti-slip ring on lens and cap.
  • Stage with clamps.
  • Lighting with independent switches.
  • Stable, robust, reinforced and easy to transport.

  • Education: Lower grade level
  • Industrial
  • Research

  • Dust cover.
  • Power cord

10-years limited warranty.
